Gothic Arch Snow Load Tunnel Greenhouse 8mm Polycarbonate Board 275gsm Zinc Steel Frame
| Tempat asal | Shandong, Tiongkok |
|---|---|
| Nama merek | wilda |
| Sertifikasi | CE, ISO 9001:2015 |
| Nomor model | GH-G820PC |
| Kuantitas min Order | 1 Set (kontainer 40HQ) |
| Harga | USD 7,800 - 10,400 / Set |
| Kemasan rincian | Panel polikarbonat dalam peti kayu dengan pemisah busa, bundel bingkai bernomor, profil aluminium di |
| Waktu pengiriman | 25-35 hari setelah setoran |
| Syarat-syarat pembayaran | T/T, L/C pada pandangan, Western Union |
| Menyediakan kemampuan | 20 set per bulan |
Detail produk
| Lebar bentang | 8 m | Panjang | 20 M |
|---|---|---|---|
| Tinggi Atap | 4,2 m | Tinggi bahu | 1,6 M |
| Profil Lengkungan | Lengkungan Gotik | Tabung Lengkungan | 60x2,0mm |
| Jarak lengkungan | 0,8 juta | Lapisan Seng | 275 g/m2 |
| Menutupi | Polikarbonat dinding kembar 8 mm | Transmisi ringan | 82 persen |
| Beban Salju | 0,55 kN/m2 | Beban Angin | 0,50 kN/m2 |
| Menyoroti | Gothic arch tunnel greenhouse,8mm polycarbonate greenhouse,275gsm zinc steel frame greenhouse |
||
Deskripsi Produk
Most collapsed tunnels we are asked to replace failed at the same place: the shoulder joint, under a snow load the frame was never rated for. This 8 m x 20 m gothic arch house is the shape we recommend above 0.45 kN/m2. The pointed profile sheds snow instead of holding it on a flat crown, the 8 mm twin wall polycarbonate cover carries its own snow load, and the frame is 275 g/m2 hot dip galvanized with 0.8 m arch spacing under the ridge. It is a heavier, more expensive
